Product Summary
The chip bidge RJ017 is a highly intergrated ASIC that conbines LAN and WAN subsytems to achiecve a full ethernet remote bridge on a single chip. The RJ017 automatically learns the MAC addresses on the LAN it is connected to, and forwards only the frames destined for another LAN.
Parametrics
RJ017 absolute maximum ratings: (1)Storage temperature: -65 to 150℃; (2)Ambient temperature under bias: -40 to +85℃; (3)Supply voltage: -0.3 to 6.0V; (4)Inputs: -0.5 to VDD +0.5V; (5)Operating temperature: -40 to +85℃.
Features
RJ017 features: (1)Glueless connection to most LAN chips; (2)Up to 40 Mbps sync WAN link; (3)Up to 115.2 kbps async WAN link with internal baud rate generator; (4)10000 address LAN table; (5)Buffer capacity of 256 frames; (6)Filtering rate of 15000 pps; (7)Forwarding rate of 15000pps.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 RJ017 |
Other |
|
Data Sheet |
Negotiable |
|
||||
