VND5004

4mΩ, high side driver, analog current sense, automotive applications, 27 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~4.00

PartNumber:: VND5004

Brand:: STMicroelectronics - ST | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-12

From Other Seller

Part Number:VND5004
US $1.00 - 4.00
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The VND5004 is a double 4mΩ high side driver with analog current sense for automotive applications. The VND5004 is a device made using STMicroelectronics VIPower technology. It is intended for driving resistive or inductive loads with one side connected to ground. Active VCC pin voltage clamp and load dump protection circuit protect the devices against transients on the Vcc pin (see ISO7637 transient compatibility table).

Parametrics

VND5004 absolute maximum ratings: (1)VCC DC supply voltage: 27 V; (2)VCCPK Transient supply voltage (T<400ms, Rload>0.5Ω): 41 V; (3)-VCC Reverse DC supply voltage: 16 V; (4)IOUT DC output current Internally limited A. IOUT Reverse DC output current: 70 A; (5)IIN DC input current: -1 to 10 mA; (6)ICSD DC current sense disable input current: -1 to 10 mA; (7)VCSENSE Current sense maximum voltage (Vcc>0V) Vcc-41 +Vcc V; (8)EMAX, Maximum switching energy(L=0.3mH; RL=0Ω; Vbat=13.5V; Tjstart=150oC; IOUT = IlimL(Typ.) ): 342 mJ; (9)VESD; (10)Electrostatic discharge (Human Body Model: R=1.5kΩ; C=100pF): 2000 V; (11)VESD Charge device model (CDM-AEC-Q100-011): 750 V.

Features

VND5004 features: (1)Max transient supply voltage VCC: 41V; (2)Operating voltage range VCC: 4.5 to 27V; (3)Max On-State resistance (per ch.) RON: 4 mΩ; (4)Current limitation (typ) ILIMH 100A; (5)Off state supply current IS: 2 μA.
