Product Summary

The 12CWQ10FN surface mount, center tap, Schottky rectifier series has been designed for applications requiring low forward drop and small foot prints on PC board. Typical applications of 12CWQ10FN are in disk drives, switching power supplies, converters, free- wheeling diodes, battery charging, and reverse battery protection.

Parametrics

12CWQ10FN absolute maximum ratings: (1)Rectangular waveform, IF(AV): 12A; (2)VRRM: 100 V; (3)IFSM @ tp = 5 μs sine: 330A; (4)VF @ 6 Apk, TJ = 125℃: 0.65V (per leg); (5)TJ range: -55 to 150℃.

Features

12CWQ10FN features: (1)Popular D-PAK outline; (2)Center tap configuration; (3)Small foot print, surface mountable; (4)Low forward voltage drop; (5)High frequency operation; (6)Guard ring for enhanced ruggedness and long term reliability.

Diagrams

12CWQ10FN simplified diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
12CWQ10FN
12CWQ10FN
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 12 Amp 100 Volt Common Cathode
Data Sheet
Negotiable
12CWQ10FNPBF
12CWQ10FNPBF

DIODE SCHOTTKY 100V 6A D-PAK
Data Sheet
0-1: $0.75
1-10: $0.66
10-25: $0.60
25-100: $0.52
100-250: $0.46
250-500: $0.41
500-1000: $0.32
1000-2500: $0.30
2500-5000: $0.28
12CWQ10FNTR
12CWQ10FNTR
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 12 Amp 100 Volt Common Cathode
Data Sheet
Negotiable
12CWQ10FNTRL
12CWQ10FNTRL
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 12 Amp 100 Volt Common Cathode
Data Sheet
Negotiable
12CWQ10FNTRR
12CWQ10FNTRR
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 12 Amp 100 Volt Common Cathode
Data Sheet
Negotiable
12CWQ10FNTRPBF
12CWQ10FNTRPBF

DIODE SCHOTTKY 100V 6A D-PAK
Data Sheet
0-1: $0.82
1-10: $0.73
10-25: $0.64
25-100: $0.58
100-250: $0.50
250-500: $0.45
500-1000: $0.35
