Product Summary
The TPS40210DGQR is a wide-input voltage (4.5 V to 52 V), non-synchronous boost controller. It is suitable for topologies which require a grounded source N-channel FET including boost, flyback, SEPIC and various LED Driver applications.
Parametrics
TPS40210DGQR absolute maximum ratings: (1)Input voltage range: VDD: –0.3 to 52 V, RC, SS, FB, DIS/EN: –0.3 to 10 V, ISNS: –0.3 to 8 V; (2)Output voltage range, COMP, BP, GDRV: –0.3 to 9 V; (3)Operating junction temperature range: –40 to 150 ℃; (4)Storage temperature –55 to 150 ℃.
Features
TPS40210DGQR features: (1)Suitable for Boost, Flyback, SEPIC, and LED Driver Topologies; (2)Wide Input Operating Voltage: 4.5 V to 52 V; (3)Adjustable Oscillator Frequency; (4)Fixed Frequency Current Mode Control; (5)Internal Slope Compensation; (6)Integrated Low-Side Driver; (7)Programmable Closed Loop Soft Start; (8)Overcurrent Protection.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() TPS40210DGQR |
![]() Texas Instruments |
![]() Current Mode PWM Controllers Wide Input Rnge Crnt Mode Boost Cntrlr |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() TPS40210DGQRG4 |
![]() Texas Instruments |
![]() Current Mode PWM Controllers Wide In Range Crnt Mode Boost Cntrlr |
![]() Data Sheet |
![]()
|
|
