Product Summary

The LTC1735CGN is a synchronous step-down switching regulator controller that drives external N-channel power MOSFETs using a fixed frequency architecture. The operating frequency (synchronizable up to 500kHz) of the LTC1735CGN is set by an external capacitor allowing maximum flexibility in optimizing efficiency. The applications of the LTC1735CGN are Notebook and Palmtop Computers, PDAs, Cellular Telephones and Wireless Modems, DC Power Distribution Systems.

Parametrics

LTC1735CGN absolute maximum ratings: (1)Input Supply Voltage (VIN):36V to –0.3V; (2)Topside Driver Supply Voltage (BOOST):42V to –0.3V; (3)Switch Voltage (SW):36V to –5V; (4)EXTVCC Voltage:7V to –0.3V; (5)Boosted Driver Voltage (BOOST – SW):7V to –0.3V; (6)SENSE+, SENSE– Voltages:1.1 (INTVCC) to –0.3V; (7)FCB Voltage:(INTVCC + 0.3V) to –0.3V; (8)ITH, VOSENSE Voltages:2.7V to –0.3V; (9)RUN/SS Voltages:7V to –0.3V; (10)Peak Driver Output Current <10μs (TG, BG):3A; (11)INTVCC Output Current:50mA; (12)Operating Ambient Temperature Range:0℃ to 85℃; (13)Junction Temperature:125℃; (14)Storage Temperature Range:–65℃ to 150℃; (15)Lead Temperature (Soldering, 10 sec):300℃.

Features

LTC1735CGN features: (1)Dual N-Channel MOSFET Synchronous Drive; (2)Synchronizable/Programmable Fixed Frequency; (3)Wide VIN Range: 3.5V to 36V Operation; (4)VOUT Range: 0.8V to 6V; (5)OPTI-LOOPTM Compensation Minimizes COUT; (6)±1% Output Voltage Accuracy; (7)Internal Current Foldback; (8)Output Overvoltage Crowbar Protection; (9)Latched Short-Circuit Shutdown Timer with Defeat Option; (10)Very Low Dropout Operation: 99% Duty Cycle; (11)Forced Continuous Control Pin; (12)Optional Programmable Soft-Start; (13)Remote Output Voltage Sense; (14)Logic Controlled Micropower Shutdown: IQ ＜ 25μA; (15)LTC1435 Pin Compatible with Minor Component Changes; (16)Available in 16-Lead Narrow SSOP and SO Packages.
