Product Summary

The 88E6061-LAJ1 is a low power Fast Ethernet (FE) switch, which provides industry-leading functionality and price-performance ratio for the cost-sensitive Small OfÞce/Home OfÞce (SOHO) gateway/switching market and enterprise desktop switching market. The Link 88E6061-LAJ1 is a 7-port Quality of Service (QoS) switch integrating a high-performance switching fabric with four priority queues.

Features

88E6061-LAJ1 features: (1)Single-chip integration of a 7-port FE QoS switch; (2)Five integrated 10/100 Ethernet PHY ports and two MII ports: Two of the PHY ports can be conTgured as copper or Tber, Multi-mode MII interfaces; (3)Virtual Cable Tester(VCT) technology; (4)Automatic MDI/MDIX crossover for 100BASE-TX and 10BASE-T ports.

Diagrams

88E6061-LAJ1 block diagram
