Product Summary

The TLE4274V50 is a low drop voltage regulator. The TLE4274V50 regulates an input voltage up to 40 V to VQrated = 5.0V (V50), 8.5 V (V85) and 10 V (V10). The maximum output current is 400 mA. The TLE4274V50 is short-circuit proof and incorporates temperature protection that disables the IC at overtemperature. A 3.3 V and 2.5 V version is also available. For information about the low output voltage types please refer to the data sheet TLE 4274 / 3.3 V; 2.5 V.

Parametrics

TLE4274V50 absolute maximum ratings: (1)Input voltage:-42V to -45V; (2)Input current:Internally limited; (3)Output voltage:-1.0V to 40V; (4)Output current:Internally limited; (5)Ground current:100mA; (6)Junction temperature:150℃; (7)Storage temperature:-50℃ to 150℃.

Features

TLE4274V50 features: (1)Output voltage 5 V, 8.5 V or 10 V; (2)Output voltage tolerance ≤±4%; (3)Current capability 400 mA; (4)Low-drop voltage; (5)Very low current consumption; (6)Short-circuit proof; (7)Reverse polarity proof; (8)Suitable for use in automotive electronics; (9)Green Product (RoHS compliant) version of TLE 4274 AEC qualified.

Diagrams

TLE4274V50 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TLE4274V50
TLE4274V50

Infineon Technologies

IC LDO VOLT REG 5V P-TO220-3

Data Sheet

1-25: $1.07
25-100: $0.92
100-1000: $0.53
TLE4274V50XK
TLE4274V50XK

Infineon Technologies

Low Dropout (LDO) Regulators Low Drop Voltage Regulator 5V

Data Sheet

0-1: $1.34
1-10: $1.15
10-100: $0.86
100-500: $0.67
