Product Summary

TLE TLE4264G is a 5-V low-drop fixed-voltage regulator in an SOT-223 package. The IC regulates an input voltage VI in the range 5.5 V < VI < 45 V to VQrated = 5.0 V. The maximum output current of the TLE4264G is more than 120 mA. This IC is shortcircuit-proof and features temperature protection that disables the circuit at overtemperature.

Parametrics

TLE4264G absolute maximum ratings: (1)Junction temperature Tj: 150 ℃; (2)Storage temperature Tstg: -50 to 150 ℃; (3)Input voltage VI: 5.5 to 45 V; (4)Junction temperature Tj: -40 to 150 ℃; (5)System-case Rth SC: 25 K/W; (6)Output voltage VQ: -1 to 16 V; (7)Output current IQ: limited internally.

Features

TLE4264G features: (1)Output voltage tolerance ≤ ± 2 %; (2)Low-drop voltage; (3)Very low current consumption; (4)Overtemperature protection; (5)Short-circuit proof; (6)Suitable for use in automotive electronics; (7)Reverse polarity.

Diagrams

TLE4264G Pin Configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TLE4264G
TLE4264G

Infineon Technologies

Low Dropout (LDO) Regulators 5V LW Drop VOLT REGULATOR 200mA

Data Sheet

0-1: $1.01
1-10: $0.91
10-100: $0.71
100-250: $0.56
TLE4264GXT
TLE4264GXT

Infineon Technologies

Low Dropout (LDO) Regulators 5-V Low Drop Fixed Voltage Regulator

Data Sheet

0-1: $0.59
1-10: $0.53
10-100: $0.49
100-500: $0.45
500-1000: $0.41
