Product Summary
The NDP6060L is a N-Channel Logic Level Enhancement Mode Field Effect Transistor. It is produced using Fairchild’s proprietary, high cell density, DMOS technology. The NDP6060L is particularly suited for low voltage applications such as automotive, DC/DC converters, PWM motor controls, and other battery powered circuits where fast switching, low in-line power loss, and resistance to transients are needed.
Parametrics
NDP6060L absolute maximum ratings: (1)Drain-Source Voltage:60V; (2)Drain-Gate Voltage:60V; (3)Gate-Source Voltage: Continuous:±16V, Nonrepetitive:±25V; (4)Drain Current: Continuous:48A, Pulsed:144A; (5)Total Power Dissipation: @ TC = 25℃:100W, Derate above 25℃: 0.67W/℃; (6)Operating and Storage Temperature:-65℃ to 175℃; (7)Maximum lead temperature for soldering purposes, 1/8” from case for 5 seconds:275℃.
Features
NDP6060L features: (1)48A, 60V. RDS(ON)= 0.025Ω @ VGS = 5V; (2)Low drive requirements allowing operation directly from logic drivers. VGS(TH)< 2.0V; (3)Critical DC electrical parameters specified at elevated temperature; (4)Rugged internal source-drain diode can eliminate the need for an external Zener diode transient suppressor; (5)175℃ maximum junction temperature rating; (6)High density cell design for extremely low RDS(ON); (7)TO-220 and TO-263 (D2PAK) package for both through hole and surface mount applications.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 NDP6060L |
Fairchild Semiconductor |
MOSFET N-Ch LL FET Enhancement Mode |
Data Sheet |
|
|
||||||||||||
