Product Summary

The OPA177GS is a precision bipolar op amp, which features very low offset voltage and drift. Laser-trimmed offset, drift and input bias current virtually eliminate the need for costly external trimming. The high performance and low cost make OPA177GS ideally suited to a wide range of precision instrumentation. The applications of the OPA177GS include precision instrumentation, data acquisition, test equipment, bridge amplifier, thermocouple amplifier.

Parametrics

OPA177GS absolute maximum ratings: (1)Power Supply Voltage: ±22V; (2)Differential Input Voltage: ±30V; (3)Input Voltage: ±VS; (4)Output Short Circuit: Continuous; (5)Operating Temperature: Plastic DIP (P), SO-8 (S): –40℃ to +85℃, qJA (PDIP): 100℃/W, qJA (SOIC): 160℃/W; (6)Storage Temperature: Plastic DIP (P), SO-8 (S): –65℃ to +125℃; (7)Junction Temperature: +150℃; (8)Lead Temperature (soldering, 10s) P packages: +300℃, (soldering, 3s) S package: +260℃.

Features

OPA177GS features: (1)low offset voltage: 25mV max; (2)low drift: 0.3mV/℃; (3)high open-loop gain: 130dB min; (4)low quiescent current: 1.5mA typ; (5)replaces industry-standard op amps: OP-07, OP-77, OP-177, AD707, ETC.

Diagrams

OPA177GS block diagram
